Central Massachusetts Machine specializes in large machining services

- Turning up to 140"
- Milling 240" x 90"
- Project Coordinating / Machining Consulting

LARGE MACHINING

HORIZONTAL BORING MILLS

Giddings and Lewis 5" Bar Floor Type, 91" x 240" Capacity Full CNC Control
G&L PMC5, 5" Bar, Table Type, 75" x 109" Travel, new Fanuc CNC Control 2008
G&L PMC5, 5" Bar, Table Type, 75" x 109" Travel, PaceSetter 2000 CNC Control
DeVlieg 4K-l20 Jig Mill, 72" x 120" Travel, Full 3 Axis CNC 48"x 48" Indexing Rotary Table
DeVlieg 5K-96 Jig Mill, 84" X 96" Travel, Fanuc 5 Axis Control, Product Rotary Table
Giddings & Lewis 6”, 108" x 84" Travel, Fanuc 5 Axis Control, CNC Rotary Table
Toshiba BMC-13B, 71” x 55” Tosnuc 500MX CNC Control w/ Rotary and Pallet System
DeVlieg 65K-120 6” Jig Mill, 72" X 120" Travel, Fanuc 4 Axis Control
DeVlieg 3K-48 Jig Mill, 48" X 48" Travel, Diatrol V Control
DeVlieg 4-B Jig Mill, 48" X 60" Travel
DeVlieg 2B-36 Jig Mills, 36" X 48" Travel, Digital Readout
DeVlieg 2B-36 Jig Mills, 36" X 36" Travel, Digital Readout

VERITCAL BORING MILLS

Berthiez Vertical Boring Mill, Maximum Swing 157", 63" Under the Rail, 75” Chuck
Cincinnati-Hypro VBM, Maximum Swing 126", 88" Under the Rail, 120" Chuck

VERTICAL TURRET LATHES

Mario Carnaghi VTL, Maximum Swing 88", 80" Under the Rail, 70" Chuck GE 2000T CNC Control
WS Gray VTL, Maximum Swing 84", 72" Under the Rail, 72" Chuck, DynaPath CNC Control new in 2006
O-M VTL, Maximum Swing 46”, 30” Under the Rail, 40” Chuck Fanuc 6T

LATHES

American CNC Lathe, 36" Over The Bed, 22" Over The Carriage 120" Between Centers, GE 7500 NC Control w/ Tape Twin
Bridgeport CNC EZPATH, 27" Over the Bed, 15" Over the Carriage, 120" Between Centers, EZPATH CNC Control

PLANER MILLS

New Haven, Double Housing, 108" Between Columns, 108" Under the Rail, 216" Travel, 30HP Milling Head, Digital Readout
Niles Biemont / Pontiac Planer Mill, 60" X 60" X 288", 30 HP Milling Head

Small Machining

TURNING

Mazak QTN-200 CNC Lathe
Okuma LC-30 CNC Lathe
Mori-Seiki SL-7 CNC Lathe
2 Cadillac Engine Lathes
Hardinge Chucker
American Pacemaker 16" X 60", Taper Attachment
Two Cincinnati Tray Tops 18" X 72"

MILLING

Kuraki KV-700 Machining Center
4 NC Bridgeports
5 Manual Bridgeports Model J, with between 36" to 42" Tables

GRINDING

13” P&W Blanchard Grinder
6” x 18” Surface Grinder
Elliot Model 921 Production Surface Grinder
KAO Ming Model KM-40-5, Tool and Cutter
Brown & Sharpe 6"X 18" Surface Grinder

SUPPORT EQUIPMENT

Overhead Cranes: 10,000 lbs – 30,000 lbs
Band Saws
MIG / TIG / ARC Welding
Tap Disintegrator
Health Ultrograph Profile Burner
Large Capacity Forktrucks

Facility 2 – Sheet Metal

Trumpf L3030 Laser
Trumpf 200R CNC Sheet Metal Processing Center
Trumpf V130 Press
Accurpress 175 ton 12’ Press Break
Accurpress 60 ton 6’ CNC Press Break
Accurpress 12’ Shear
AEM / Timesaver 37” Dry
2 Bridgeport Manual Machining Centers
Chevalier Milling Center
Sycrowave TIG Welding Machines
Piranha Metal Punch
Pemsetter Series 2000 Inserter
Pemsetter Series 4
Niagara 6’ Roll Former
Ercolin Tubing / Pipe Bender
Hyd-mech S20A Auto Feed Bandsaw
Variety of Belt Sanding Equipment
Hand Plasma Cutters
8’ Portable Hand Breaks
Alphil Spot Welder
Cutlass & AGM Stud / Pinwelders
Portable Welding, Plasma and Fabricating Capabilities

Facility 3 – Fabrication
